• Features

Límites de operación:
Presión: ≤2.1MPa
Velocidad: ≤25m/s
Temperatura: -30℃~+205℃


● Anillo giratorio (SiC/TC)
● Anillo estacionario (SiC/TC/Carbono)
● Sello secundario (VITÓN/Anillo encapsulado/PTFE)
● Fuelles metálicos (SUS316L/AM350/Inconel718/Titanio/Hastelloy-C/Aleación-20)
● Otras piezas (SUS304/SUS316/ Titanio/Hastelloy-C)

d1	d2	d4		d26	l12	l23	l39	l56	l90	l91	l92	m	n
		min	max
1.000	1.375	1.445	1.889	4.000	1.989	1.353	1.954	0.531	2.000	0.160	0.035	0.525	2.805
1.125	1.500	\	2.015	4.125	2.062	1.446	2.062	0.531	2.125	0.125	\	0.525	2.933
1.250	1.625	\	2.294	4.250	2.062	1.446	2.062	0.531	2.125	0.125	\	0.525	3.213
1.375	1.750	\	2.421	4.375	2.062	1.446	2.062	0.531	2.125	0.125	\	0.525	3.338
1.500	1.937	2.007	2.680	4.875	2.156	1.487	2.125	0.593	2.187	0.156	0.031	0.525	3.599
1.625	2.062	2.132	2.812	5.000	2.156	1.487	2.125	0.593	2.187	0.156	0.031	0.562	3.766
1.750	2.170	2.240	2.918	5.250	2.156	1.487	2.125	0.593	2.187	0.156	0.031	0.562	3.875
1.875	2.312	2.382	2.918	5.250	2.156	1.487	2.125	0.593	2.187	0.156	0.031	0.562	3.875
2.000	2.437	2.507	3.015	5.500	2.375	1.601	2.312	1.063	2.375	0.187	0.062	0.562	4.000
2.125	2.562	2.632	3.360	5.859	2.375	1.601	2.312	0.593	2.375	0.187	0.062	0.687	4.469
2.250	2.687	2.757	3.485	6.500	2.375	1.601	2.312	0.593	2.375	0.187	0.062	0.687	4.566
2.375	2.812	2.882	3.610	6.500	2.484	1.717	2.466	0.625	2.528	0.143	0.018	0.687	4.719
2.500	3.062	\	3.891	6.750	2.484	1.717	2.563	0.625	2.625	0.125	\	0.687	5.000
2.625	3.312	\	4.062	6.750	2.500	1.625	2.500	0.625	2.562	0.125	\	0.687	5.170
2.750	3.312	\	4.062	6.750	2.500	1.625	2.500	0.625	2.562	0.125	\	0.687	5.170
2.875	3.375	\	4.186	7.000	2.500	1.725	2.500	0.625	2.562	0.125	\	0.687	5.312
3.000	3.625	\	4.469	7.750	2.500	1.787	2.562	0.685	2.625	0.125	\	0.812	5.720
