• Features

Límites de operación:
Presión: ≤2MPa(Parte con onda simple)
≤6.9MPa(Parte con onda doble)
Speed: ≤25m/s
Temperatura: -75℃~+425℃

● Anillo giratorio (SiC/TC/Carbono)
● Anillo estacionario (SiC/TC)
● Sello secundario (Carbono flexible)
● Fuelles metálicos (SUS316L/AM350/Inconel718/Titanio/Hastelloy-C/Aleación-20)
● Otras piezas (SUS304/SUS316/ Titanio/Hastelloy-C)

Eje (pulgadas)	d	d1	l
1.000	1.000	1.625	1.531
1.125	1.125	1.750	1.562
1.250	1.250	1.875	1.593
1.375	1.375	2.000	1.593
1.500	1.500	2.125	1.593
1.625	1.625	2.250	1.593
1.750	1.750	2.375	1.625
1.875	1.875	2.500	1.625
2.000	2.000	2.625	1.656
2.125	2.125	2.750	1.656
2.250	2.250	2.875	1.719
2.375	2.375	3.000	1.719
2.500	2.500	3.250	1.750
2.625	2.625	3.375	1.781
2.750	2.750	3.500	1.781
2.875	2.875	3.687	1.875
3.000	3.000	3.812	1.875
3.125	3.125	4.000	1.875
3.250	3.250	4.125	1.875
3.375	3.375	4.250	1.875
3.500	3.500	4.375	1.875
3.625	3.625	4.500	1.875
3.750	3.750	4.625	1.875
3.875	3.875	4.750	1.875
4.000	4.000	4.875	1.875
